ButylShield60 Pro (Chloro) : Butyl Rubber Sheet
What is ButylShield60 Pro (Chloro)?
The Duratuf ButylShield60 Pro – Chloro belongs to our premium Butyl rubber sheet category. It is made of high-quality chlorinated Butyl rubber. The composition of these rubber sheets offers a unique combination of chemical resistance, low permeability, and high heat resistance.
The ButylShield60 Pro – Chloro Butyl rubber sheeting has excellent resistance to dilute acids-bases and concentrated acids-bases.
We recommend using this chlorine-based Butyl sheet in chemical, pharmaceutical, and automotive industries. Their proven resistance to UV and Ozone makes the this chloro butyl sheeting highly durable in challenging environments. This product has no filler in it and a 100% polymer content.
You can find the full tech specs of the ButylShield60 Pro – Chloro below:
Technical Specifications of ButylShield60 Pro (Chloro) Rubber Sheet
| MEASURED PROPERTIES | TESTING STANDARD | SPECIFIED VALUES | OBSERVED VALUES |
|---|---|---|---|
| Tensile Strength | ASTM D412 | 8.0 MPa (min) | 8.6 MPa |
| Elongation at Break | ASTM D412 | 350% (min) | 365% |
| Hardness | ASTM D2240 | 60° ± 5° Shore A | 62° Shore A |
| Specific Gravity | ASTM D297 | 1.20 ± 0.05 | 1.22 |
| Working Temperature | – | -40°C to +130°C | Conforms |
| STANDARD DIMENSIONS & POLYMER COMPOSITION | |||
| Size | 2~12mm Thk. x 1.2m Wide x 10m Long | Finish Type | Top & Bottom Plain |
| Color | Black | Polymer | Chloro-Butyl – 100% |
Key Features and Properties of ButylShield60 Pro (Chloro)
Reliable Chemical Protection
Performs in acidic, alkaline, and solvent-heavy zones—ideal for tank linings and process seals.
Dynamic Flex Performance
Stays flexible under stress—works well in moving joints, ducts, and pump housings.
Extreme Temperature Stability
Suitable for cold storage and high-heat pipelines—reduces material failure risks.
Contamination-Free Use
Low out-gassing and non-marking—trusted in pharma, food-grade, and cleanroom environments.
Long-Term Durability
Withstands weathering, oxidation, and aging—reduces replacement frequency and cost effectively.
Installation Friendly
This Butyl sheeting is lightweight and adaptable—easy to cut, bond, and install on-site.
Common Uses of ButylShield60 Pro (Chloro) rubber sheet
- Chemical tank and pipeline linings
- Vapor and gas sealing systems
- Flange and gasket sealing in corrosive areas
- Protective covers in ozone-prone outdoor setups
- Pharmaceutical and chemical storage seals
- Low-pressure vacuum environments
- Protective curtains in acid wash bays
Industry Certifications And Memberships
Why Duratuf for ButylShield60 Pro (Chloro) rubber sheet?
Timely Delivery
We make sure to deliver on time and enhance customer experience.
Order Tracking
Track your orders from our website to stay updated.
Scalable Supply
Supports increasing production volumes to match project needs.
Flexible Dispatch
Choose among CIF, FOB, Ex-works, CFR, and more delivery methods.
Our Client Testimonial / Success Stories
Omar Hassan
I must say that Duratuf Products provided me EPDM rubber sheets of top quality. The sheets delivered by you guys are perfect for applying in my workplace’s industrial tanks! The order was delivered to us on time so a big thanks to you people.
Chris Taylor
On-time delivery: Thank you Duratuf for the EPDM rubber sheets of top quality. The sheets delivered by you guys are best for applying in my workplace’s industrial tanks! The order was delivered to us on time so a big thanks to the sales and support team.
Sakshi B
I’ve long sought a dependable solution for our sealing applications. Thanks to your Viton Rubber Sheets, our search is finally over. These sheets have revolutionized our sealing processes, offering unparalleled resistance to extreme temperatures, chemicals, and pressure.
Rajiv Barua
The Nitrile Rubber Sheets exhibit exceptional resistance to oils, fuels, and abrasion, making them ideal for our demanding applications in the automotive sector. Very happy with customer services.
Anil Patel
Thanks to Duratuf’s reliable products, we’ve achieved higher operational efficiency and productivity levels. I wholeheartedly endorse their Skirt Board Rubber Sheets to fellow industry professionals seeking dependable performance.
Anita Singh
As the proprietor of a manufacturing unit in Kolkata, India, I’ve relied on Neoprene Rubber Sheets from Duratuf to meet our demanding industrial requirements. The Neoprene material’s resilience against abrasion, weathering, and oil has significantly enhanced the durability of our products.
Vikram Singh
As a steel fabrication company based in Mumbai, India, maintaining the integrity of our equipment is essential. These rubber sheets have significantly enhanced the efficiency and safety of our blasting processes.
Suresh Menon
The quality and reliability of your pulley lagging sheets are very good. They provide exceptional traction and wear resistance, even under the most demanding conditions. Our machinery’s performance has improved significantly since we started using these sheets, reducing downtime and maintenance costs.
Rajesh Kumar
Living in Chennai, India, I’ve struggled to find a reliable solution for my industrial needs until I discovered Silicone Rubber Sheets from Duratuf. The quality of the silicone is impeccable, offering unmatched resistance to extreme temperatures and chemicals, crucial for our diverse applications.
Steven Miller
After placing my first order, I was thoroughly impressed with Duratuf’s easy ordering process and attention to the customer’s needs. The insertion rubber sheet provided to us has surpassed my expectations, proving to be an essential component in our production line.
Sarah Johnson
I run a small manufacturing unit specializing in inflatable products. We recently switched to Hypalon rubber sheets supplied by Duratuf for our production line, and the difference has been remarkable.
R. Patel
As a customer based in London, I’ve been thoroughly impressed by the Natural Rubber Sheet offered by Duratuf. Its eco-friendly composition aligns perfectly with my values.
Anastasia Ivanova
Being in the heart of monsoon-prone Mumbai, finding a reliable waterproofing solution was paramount for our construction project. We chose the EPDM Rubber sheets, and it has exceeded our expectations. Thanks to this innovative product, our investment is protected for years to come. Highly recommend it to fellow developers!
Omar Hassan
I must say that Duratuf Products provided me EPDM rubber sheets of top quality. The sheets delivered by you guys are perfect for applying in my workplace’s industrial tanks! The order was delivered to us on time so a big thanks to you people.
João Pereira
I recently purchased Butyl Rubber Sheets for a project, and I must say, I am thoroughly impressed with their quality and performance.
Diego Martinez
The Abrasion Resistant Rubber Sheet exceeded our expectations, providing exceptional protection against wear and tear.
Oliver Smith
The General Purpose Rubber Sheet is a game-changer for us. It seals effectively, withstands extreme conditions, and saves time and resources. Highly recommended for reliable sealing and insulation
Bruce Budden
Insulated mat from Duratuf Products are not like other common commercial rubber mats. Easy to use, flexible, durable and the best quality at affordable price. I strongly recommended these to ensure the safety of workplace.
Ajinkya Vartak
We have purchased insulating mats from Duratuf because of their high quality. I appreciate Mr. Samsul Haque sir as he handled dispatch and product quality. Mr. Debapriyo Nandi, logistic Coordinator assists for transportation & excellent packing quality.
Suresh Babu Dasari
Quality of the products are reallly good and trustworthy. People of this organization are very professional and proactive.
Frequently Asked Questions
What material is ButylShield60 Pro – Chloro made from?
It is manufactured using 100% Chlorobutyl (CIIR) rubber, engineered for superior gas barrier performance, aging resistance, and chemical durability.
What is ButylShield60 Pro – Chloro rubber sheet used for?
ButylShield60 Pro – Chloro is used for chemical tank linings, vapor and gas sealing systems, flange gaskets in corrosive areas, vacuum seals, ozone-prone outdoor covers, and pharmaceutical storage applications where low permeability and chemical stability are essential.
What is the hardness of ButylShield60 Pro – Chloro?
The sheet has a nominal hardness of 60 ± 5 Shore A (ASTM D2240), offering a balance of flexibility and structural integrity for sealing applications.
What are the tensile strength and elongation properties?
As per ASTM D412, Tensile Strength: Minimum 8.0 MPa (Observed 8.6 MPa) and Elongation at Break: Minimum 350% (Observed 365%). These properties ensure reliable flexibility and long-term durability under stress.
What is the working temperature range?
ButylShield60 Pro – Chloro performs effectively between –40°C to +130°C, making it suitable for both low-temperature and high-heat industrial environments.
How resistant is ButylShield60 Pro – Chloro to chemicals?
The sheet offers: Excellent resistance to ozone, dilute and concentrated acids & bases and oils also Fair resistance to certain chemicals but Not recommended for solvents. This makes it suitable for chemically aggressive zones.
Does ButylShield60 Pro – Chloro provide low gas permeability?
Yes. Chlorobutyl rubber provides very low gas and vapor transmission rates, making it ideal for containment, vacuum environments, and leakage control applications.
