If you work with or around low-voltage electrical equipment rated up to 3.3 kV, you need the right protection underfoot. The IS 15652 Class A electrical insulating rubber mat is the most widely used safety mat for LT panels, switchgear rooms, control rooms, and distribution boards across India.
This guide covers everything you need to know, from technical specifications and where to use it, to how to choose and buy the right mat.
What is an IS 15652 Class A Electrical Insulating Mat?
An IS 15652 Class A electrical insulating rubber mat is a specialized rubber floor mat designed to protect workers from electric shocks in areas where voltages go up to 3.3 kV (3,300 volts). It is manufactured and tested according to IS 15652:2006, the Indian Standard set by the Bureau of Indian Standards (BIS) for electrical insulating mats.
Class A is the entry-level classification under IS 15652. It is meant for low-tension (LT) electrical environments like control panels, distribution boards, battery rooms, and similar setups where voltages do not exceed 3.3 kV.
Technical Specifications of IS 15652 Class A Mat
Here are the key technical details of the Duratuf XVolt Class A insulating mat (IS 15652:2006):
| Specification | Value |
| Product Code | IM-XV-CA |
| IS Standard | IS 15652:2006 |
| Class | A |
| Standard Thickness | 2.0 mm |
| Max Use Voltage (AC) | 3.3 kV (3,300 V) |
| AC Proof Voltage | 10 kV |
| Dielectric (Withstand) Voltage | 30 kV |
| Leakage Current (Max) | 10 mA |
| Tensile Strength (Min) | 15 N/mm² |
| Elongation at Break (Min) | 250% |
| Insulation Resistance (at 5000V, with water) | 1,00,000 MΩ (min) |
| Flame Retardance | Extinguishes within 5 seconds |
| Working Temperature Range | -10°C to 55°C |
| Standard Roll Size | 10 m length x 1 m width |
| Available Cut Sizes | 1 m x 2 m (ready stock) |
| Max Customisable Width | Up to 1500 mm |
| Available Colours (Standard) | Black, Blue |
| Custom Colours Available | Red, Grey, Green, Yellow and others |
| Anti-Skid Design | Dotted top surface, Textured bottom surface |
| Weight per m2 (Approx) | 3.2 kgs |
| Warranty | 12 Months |
What Does ‘Class A’ Mean Under IS 15652?
IS 15652:2006 divides insulating mats into three classes such as class A, B, and C based on the voltage level they can safely handle. Here is a quick comparison to understand where Class A fits:
| Specification | Value | |||
| Class | Max Use Voltage | AC Proof Voltage | Dielectric Voltage | Thickness |
| Class A | 3.3 kV | 10 kV | 30 kV | 2 mm |
| Class B | 11 kV | 22 kV | 45 kV | 2.5 mm |
| Class C | 33 kV | 36 kV | 65 kV | 3 mm |
Class A mats are the thinnest and most lightweight of the three classes, making them easy to lay and handle. They are ideal when your working environment involves voltages at or below 3.3 kV.
Where Should You Use an IS 15652 Class A Electrical Insulating Mat?
Class A mats are widely used in the following low-voltage environments:
- LT (Low Tension) Control Panels: Distribution boards, circuit breaker panels, and feeder pillar boxes
- Switchgear Rooms: In front of low-voltage switchgear and MCCBs
- Control Rooms: Operator workstations at power plants or industrial facilities
- Battery Rooms: In front of battery charging stations and storage racks
- Data Centres: UPS rooms, server room power distribution areas
- Electrical Laboratories: Around circuit testing benches and low-voltage equipment zones
- VFD Cabinets: Variable Frequency Drive enclosures and motor control centres (MCCs)
- Substation Control Rooms: Secondary voltage areas inside an electrical substation
If your work area has voltages at or below 3.3 kV, this mat is your go-to safety solution.
Key Features of the Duratuf XVolt Class A Insulating Mat
1. BIS Certified (IS 15652:2006)
The XVolt Class A mat carries the ISI mark with BIS License No. CM/L-8385793. This means the mat has been tested by accredited, internationally recognized laboratories, not just local labs. Every meter of the mat is marked with the product name, class, and standard for easy authenticity verification.
2. Anti-Skid Design for Worker Safety
The top surface features a dotted anti-skid pattern, while the bottom has a smart slip prevention design to prevent the mat from slipping on the floor. This dual-grip design reduces the risk of slips, trips and falls, a critical feature in busy industrial environments.
3. Flame Retardant
In the event of an electrical fault, the mat extinguishes itself within 5 seconds. This stops the spread of flames and significantly reduces the risk of fire accidents in electrical rooms.
4. Resistant to Oil, Acid, Alkali, and Moisture
Industrial environments are rarely clean. The XVolt mat resists mild acids, alkalis, oils, water, and moisture, maintaining its insulating properties even in challenging conditions.
5. Premium Elastomer Material
The mat is made from a premium-grade elastomer free from any insertion. This is a specific requirement under IS 15652 and ensures the material provides consistent, high electrical resistance throughout its lifespan.
6. Test Certificate Provided with Every Supply
Duratuf Xvolt electrical mats are type tested from NABL-accredited labs. We provide the test certificates with every supply. This is crucial for safety audits, government inspections and compliance documentation.
7. 12-Months Warranty
The XVolt Class A mat comes with a 12-months manufacturer’s warranty covering manufacturing defects and giving you long-term peace of mind.
How to Install a Class A Insulating Mat: Step by Step Guide
- Clean the Surface: Make sure the floor area is clean, dry, and free of debris or oil before laying the mat.
- Position the Mat: Lay the mat flat in front of the electrical panel or equipment, ensuring it covers the entire standing area.
- Secure the Mat: Use adhesive or double-sided tape if needed to keep the mat from shifting during use.
- Align Multiple Mats: If you need to cover a larger area, align mats edge-to-edge without overlapping. Overlapping seams can create trip hazards and reduce insulation effectiveness.
How to Store and Maintain Your Class A Insulating Mat
Proper storage and care will extend the life of your mat and keep it performing at its best.
- Store in a clean, cool, and dry environment. Away from direct sunlight, heat sources, and ozone-generating equipment.
- Roll or lay flat. Never fold the mat, as folding can cause creases that weaken insulation.
- Inspect before every use. Look for cuts, tears, abrasions or surface irregularities.
- Clean with a mild detergent and wipe dry. Do not use harsh chemicals.
- Remove from service immediately if damage is found. A damaged mat should never be used near live electrical equipment.
Why Choose Duratuf XVolt for Your Class A Insulating Mat?
With over 15 years in the business and 3,793+ happy customers across 61+ countries, Duratuf is one of India’s most trusted names in electrical insulating mats. Here is what sets the XVolt apart:
- 10,000 sq. m. of ready stock available across 7 warehouses in India and UAE
- Expert response within 60 minutes of your enquiry
- Free consultation from industry experts
- Competitive pricing despite high-end quality
- Bright, vibrant colours that add to the aesthetic appeal of your facility
- Custom sizes, widths, lengths, and colours available on request
- Used by major clients including Tata Power, CESC, BrahMos Aerospace, Maruti Suzuki, and many more
